The Airgain Whip Base Adapter is a patent-pending accessory that enables easy integration of Land Mobile Radio (LMR) whip antennas into public safety, utility, and fleet vehicles—without drilling an additional hole. Designed to mount directly under existing bolt-mount antennas, it allows users to add VHF, UHF, and 700–900 MHz whip antennas to the MULTIMAX 5G™, RECON13™, and AC-Fleet™ platforms in minutes.
Whether you’re modernizing your fleet or retrofitting your current connectivity solution, the Whip Base Adapter ensures a clean, watertight installation using Airgain’s proven mounting approach—saving time, preserving resale value, and enhancing field communications.
| AP-WP-B | Whip Base Adapter with EZConnect, 1 ft coax (black) |
| CH-P-A-14 | EZConnect cable harness with Mini UHF connector, 14 ft |
| Supported Frequencies | VHF (30–300 MHz), UHF (300–600 MHz), 700–960 MHz |
| Connector Type | M6 x 0.75mm stud mount |
| Max Radio Power | Up to 100W |
| Dimensions | 8.5” x 2.0” x 1.0” (215 x 50 x 26 mm) |
| Weight | 0.6 lbs (0.5 kg) |
| Color | Black |
| Operating Temp Range | –40ºC to 85ºC (–40ºF to 185ºF) |
| Humidity Tolerance | 95% RH at 60°C (non-condensing) |
| Environmental Protection | IP67 and IP69K |
| Shock & Vibration | MIL-STD 810G Compliant |
| Environmental Safety | RoHS Compliant |
